Stay protected on all sides with our Black Box Fleet Dash Cam system, sporting a superior 3 to 8 heavy-duty night vision camera setup that feeds into a 7-inch LCD screen (or an optional 10-inch LCD upgrade). Save yourself from false accusations with cameras that record every detail 24/7 for up to 2000 hours in tamper-proof storage up to 4TB HDD and 512GB SSD.
- Cameras: 1080N, weatherproof, waterproof, heavy-duty, night vision camera with wired and wireless options.
- Microphone Cameras: Will only operate on Channels 1-4
- Viewpoints: Record 3 to 8 viewpoints with 1080N HD cameras equipped with night vision
- Monitor: Use with our default 7" LCD Monitor or an optional 10" LCD upgrade
- Monitor Extension: Extend the screen into the sleeper with an HDMI or VGA cable, so drivers can inspect their surroundings safely if they hear a disturbance outside
- Memory: Store critical footage in a large memory up to 4TB HDD or 512GB SSD of storage, perfect for up to 2000 hours of recording
- Continuous Loop Recording: Continue recording even after storage space is full as the system deletes old videos for new videos
- Tamper-Proof System: Impossible for the driver to turn off the system and edit or delete videos
- GPS: Includes GPS to Record Speed and Location
- Cables: Select from a range of cable lengths (9, 15, 30, 45, 60, and 90 feet) to use in your setup or go wireless (see below)
- Free Shipping: Get USPS Priority shipping within 1 to 3 days and a 30-Day Money-Back Guarantee
- Easy Install: Install this wireless camera DVR system yourself in a few hours without hiring a company to install it
- SD Card Reader for Phones and Tablets: Transfer Video to Phone or Tablet in Seconds CLICK HERE
If you want to avoid accidents on the road or when changing lanes or backing into tight spaces, this camera system was built for you. Say goodbye to false traffic violations! This setup includes a GPS that records vehicle speed and location on all video files. All you need is a USB thumb drive to transfer the files you need to defend yourself.
Unlike other systems, the Black Box Dash Cam is tamper-proof. Not even the driver can access the video footage or edit it. The 1080N HD cameras are all weatherproof and waterproof with different cables, optional wireless connectivity, and camera types to match your needs.
Email us at jimmy@dashcam.co or call us at 972.600.1320 for a discount on multiple orders.
VIDEOS
PRODUCT INFORMATION VIDEO
Watch video
Watch video
DRIVING VIDEO
Customer Close Call Rear ended Video
Watch video
Watch video
Watch video
LOCOMOTIVE CUSTOMER INSTALL VIDEO
Watch video
CAMERAS
If you are looking for a top of the line 3-8 Camera MDVR Black Box system, perfect for truckers and trucking companies, this system is perfect for you. Plus, we are so confident that you will like this system, we will offer you a 100% Money Back guarantee, so there is no risk for you to try this system out! And if you want to get a quote for multiple systems, we can send you a FREE detailed discount quote today, email jimmy@dashcam.co or call us at 972.600.1320
CAMERA OPTIONS
Purchasing the Black Box Fleet Dash Cam system allows you to choose from four different 1080N camera options at no extra cost. You can add up to 4 during your order or later for maximum protection from all angles. The cameras have the same 1080N quality, the only difference is the housing type and number of IR lights. When ordering, you can select one cable per camera for free; cables come in 9, 15, 30, 45, or 60 feet.
Heavy Duty 1080P IP68K Camera - An extremely heavy-duty camera with adjustable up/down bracket designed for indoor, outdoor, dash or side installation. The bracket and housing are constructed of rugged metal and is designed to reduce wind resistance. Utilizing advanced technology to record sharp and vivid image quality. Equipped with built-in 16 IR LED to capture video in low/no light environment with Auto White Balance. (AWB) setting helps your camera “guess” the best option or choose the one closest to what your eyes might see. White balance is the process that the camera uses to remove color casts produced by these different color temperatures and helps your camera emulate what our eyes do naturally when dealing with white. *This weatherproof, heavy duty camera can be installed anywhere.
360 degree viewing:
Aerodynamic 1080P Camera extremely versatile camera with adjustable angle designed for indoor, outdoor, dash or side installation. The housing is constructed of rugged metal and is aerodynamically designed to reduce wind resistance. Utilizing advanced technology to record sharp and vivid image quality. Equipped with built-in 12 IR LED to capture video in low/no light environment.
360 degree viewing:
Bar Bracket 1080P Camera - Easily installed and attached to any pole or bar style rear view mirror. This 1080N camera has 10 IR lights for low-light environments.
360 degree viewing:
Mini 1080P MDVR Camera with IR lights This wired bracket water-proof camera comes with a 7 high-powered IR LEDs for 15-20 feet night vision in total darkness. Aluminum alloy metal case with 6.8G-force rated shock resistance, IP68 waterproof of resistance grade, and mounting bracket.
360 degree viewing:
Dome Cam: For Interior Use Only
WANT TO MAKE THIS SYSTEM WIRELESS??
Convert your Wired Camera to Wireless or Add a Wireless Camera to your Wired System.
Our 1080N 4 pin connector wireless transmitter and receiver set works perfectly for this system. It is designed for wired cameras with a 4 pin connector to connect to other camera via wireless transmitter/receiver to a place where it would be difficult to pull cables (as in the semi-trailer truck). The installation is very simple. CLICK HERE FOR THE FULL DETAILS.
IF YOU NEED ACCESSORIES FOR THIS SYSTEM CLICK HERE
Whatever you transport - Flatbed, Specialized Trucking Trailers such as Step Deck Trailers, RGN – (Removable Gooseneck Trailer), Lowboy Trailers, Dry Vans & Enclosed Trailers, PO (Power Only), Flatbed Stretch Trailer, Extendable Double Drop Trailers, Refrigerated/Reefers, Conestoga, Tank Trailers/Tankers, Heavy Haul, Side kit Trailers, Lowboy Trailers, Stretch RGN or Removable Gooseneck and Over Dimensional freight trailers. Or, Commercial & Industrial, Fire & Safety, Farm & Ranch, Travel Trailer and more.
You can customize a multi-camera system to Protect Yourself from Other Drivers on the Road while Monitoring & Recording Your Transport.
No matter what or how you transport, your 4 to 8 channel Multi-Camera System can be configured to your exact needs. Cameras can typically be mounted anywhere you want to give you the kind of coverage you need both inside and outside your vehicle. System can record all events around your vehicle, power continuously for constant 24-hour recording.
DETAILS
7-inch DASH MOUNTED LCD: This system comes with a 7-inch dash-mounted LCD screen, upgradable to 10-inch during checkout. You can then view the live feed on a full-screen for one camera or split-screen for a multi-camera setup. Record up to 8 viewpoints at once to stay protected.
Additional Benefits:
- Owner password-protected and lockable dual SD slots, so only owners can access videos.
- Records 3-8 time-stamped viewpoints in 1080N HD quality
- Loop records video continuously, replacing old video recordings with new footage
- Three 120-degree, Wide Angle, 1080N, Heavy-Duty, Weatherproof, Commercial Grade cameras included; can add up to 8 cameras.
- Records up to 1200 hours in a 4 TB of memory before loop recording, depending upon the number of cameras.
- Can use up to a 256GB SD card
- Multi-Camera Heavy Duty Camera System with 4 Channels.
- 2 Piece Unit, Separate Black Box DVR & Separate Monitor.
- Unit comes with 7" LCD Monitor, can upgrade to 10" LCD for a nominal upgrade fee.
- 4 Different 1080N Camera Styles Available: HD Bracket, Side Mount, Bar Bracket Cam, and Mini MDVR
- Monitor & Cameras Include MOUNTING Brackets
- Playback GPS Included Records Additional Metadata to SD Card.
- GPS Playback Can Show Vehicle Route, Speed, Time, Date & More
THIS SYSTEM DOES NOT HAVE 4G / LTE / WIFI TECHNOLOGY THAT ALLOWS TO VIEW CAMERAS IN REAL TIME ANYWHERE INTERNET IS AVAILABLE THROUGH A MOBILE APP OR IP URL BROWSER SERVER.
To view our 4G/LTE/WIFI dash cam product line up, CLICK HERE
MEMORY
Note: If SDD is installed (max 4TB), all recordings will save to the SDD. It will not record to SD cards. Once SDD reaches capacity, the loop recording feature goes into effect and will start recording over older video. The only time videos will record to SD Cards is when the SDD is not inserted/detected or SDD becomes defective.
Includes 2 SD card slots and 1 SDD slot securely stored inside a locked door and can only be accessed by included key. You can purchase up-to two 256GB SD cards from us or purchase any Class 10 or higher SD cards. At this time, we do not sell single disk drives. SDD slot can accept up to 4TB SDD.
Each SD slot (2) memory size max is 128GB for a total of 256GB of video storage space. 1 SDD slot with max 4TB of video storage space
Length of Recording Time (4 Cameras)
-
15 Hrs with 128GB (SD CARD)
-
160 Hrs with 1TB (SDD Drive)
-
320 Hrs with 2TB (SDD Drive)
- 640 Hrs with 4TB (SDD Drive)
*number of hours vary based on how many cameras are connected and resolution settings.
Video will continuously record based on SD or SDD memory size. Loop recording starts once storage space has maxed out.
Note: If SDD is installed (max 4TB), all recordings will save to the SDD. It will not record to SD cards. Once SDD reaches capacity, the loop recording feature goes into effect and will start recording over older video. The only time videos will record to SD Cards is when the SDD is not inserted/detected or SDD becomes defective.
HDD DRIVE PORT INFORMATION:
- Any 2.5" HDD/SSD that is a drive with at least 5400 rpm or above, up to 4 TB
SOFTWARE
SPECS
- Operational System: Linux
- Resolution: Chipset Hi-3520
- Compression: H.264
- Signal System:PAL:25 fps, NTSC: 30 fps
- Language: English or Chinese, OSD Menu
- Display Frame Rate:1080N X 960P, 1080N
- Video Input/Output: 8-CH Input/1CH Output
- Audio Input/Output: CH 1-4 Input/1CH Output
- Alarm Input/Output: 4 CH alarm Input/2 Output
- Recording: Manual, Scheduled, Motion Detection, GPS Vehicle Tracking, Speed Detection, Sync Time, Event Sensor trigger, Speeding, Accelerator, Temperature, Video Loss
- Playing Mode: Supports 1 channel or synchronous 8 channels by PC
- Searching Mode: By time/By date/By event
- Storage: Supports single SD card, up to 128GB SD Card Per SD Card Slot. Supports Single HDD drive slot, up to 4TB storage drive (not included)
- Model: G Sensor, GPS Included
- Remote Control: IT Remote Control
- Software Upgrade: SD Card or thumb drive via USB
- Power Input/Output:8-36V Input, 12V Output
Power Cable Lengths of LCD's and Cameras:
- Length of cable between LCD to power source: 85" & 1/2
- Does this product grid lines: No
- Length of power cable camera: 19"
INCLUDED
- 8 Channel MDVR Black Box Unit
- 1 – Quad Screen 7” LCD Monitor (can upgrade to 10" LCD during checkout) with Dash Mount & Remote
- 1 – 1080N Heavy Duty Bracket Sony Camera (Weatherproof, can be used inside or outside) with Auto White Balance. (AWB) setting helps your camera “guess” the best option or choose the one closest to what your eyes might see. White balance is the process that the camera uses to remove color casts produced by these different color temperatures and helps your camera emulate what our eyes do naturally when dealing with white.
- 1 – 15-foot Extension Cable for main camera
- 2 – 1080N Indoor/Outdoor Aerodynamic Side Cameras
- 2 – 30-foot Extension Cables for 2 Outside Cam
- 1 12 Volt Hard Wire Power Cable for Monitor
- 1 AV/OUT LCD Cable
- 1 HDMI PORT
- 1 VGA PORT
- 1 USB PORT
- 1 GPS Antenna
